RCBO Circuit Breaker 1P+N 6 Amp 240V AC 10kA DIN Mount

Description

RCBO Circuit Breaker Type A Compact, 6 Amp, 240 Volt AC, 50/60 Hz, Interrupt Capacity: 10 kA, Trip Sensitivity: 30 mA, Number of Poles: 1P + N, Trip Characteristic: C Curve, 10-16/25 mm Terminal Connection, IP20, DIN, Black Handle,-5 to 55 deg C, 90mm Height, 17.8mm Width, 74.4mm Depth

Key Specifications

Brand	SFR
Product Type	RCBO Circuit Breakers
SKU	SFRSE3NC6
Color	Black Show more colours

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Provides overload, short circuit and earth leakage protection Provides protection in the event of direct/indirect contact by the human body Provides comprehensive protection to residential and commercial distribution systems Provides protection against insulation failure Can be mounted on busbar chassis Handle is sealable and padlockable (with padlock attachment) Comes with function earth wire (white) and neutral wire (black) Positive contact indication
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	SFRSE3NC6
Interrupt Capacity	10 kA
Number Of Poles	1 Pole
Trip Sensitivity	30 mA
Colour	Black Handle
IP Rating	IP20
Trip Characteristic	C Curve
Height	90mm
Width	17.8mm
Depth	74.4mm
Frequency	50/60 Hz
Mounting Method	DIN
Temperature	-5 to 55 deg C
Terminal Connection	10-16/25 sq-mm
