B&R Enclosures New South Wales Series Meter Enclosure 600x600x270mm 12 Pole DIN Mount IP23 Pre-Drilled 5m Black

Description

Meter Box New South Wale, Service Facilities: 11 Module, 12 Poles, 600mm Height, 600mm Width, 270mm Depth, 560mm Panel Height, 575mm Panel Width, Top Hinged Door, IP23, DIN, Steel, Black, Galvanised

Key Specifications

Brand	B&R
Product Type	Meter Boxes Domestic
SKU	B&RNSW/BD/GD10
Color	Black Show more colours

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Designed for both single and multi-phase installations Suitable for domestic and light commercial installations Provides versatility with a large range of products and accessories Entry level range of enclosures Top hinged with panel DIN panel cut-out Earth and neutral links NOT included Manufactured from 1.0mm or 1.2mm galvanised steel to Z275
Standard Pack Size	1
UNSPSC Class	39121100
UOM	EA
Vendor Product	NSW/BD/GD10
Colour	Black
IP Rating	IP23
Material	Steel
Number Of Poles	12 Pole
Service Facilities	11 Module
Finish	Galvanised
Mounting Method	DIN
Enclosure Depth	270mm
Enclosure Height	600mm
Enclosure Width	600mm
Panel Height	560mm
Panel Width	575mm
Door Type	Top Hinged
