Meter Box NSW 12P W600mm H600mm D270mm DIN Mount Black

Description

Meter Enclosure, 12 Pole, 600 mm Height, 600 mm Width, 270 mm Depth, 560 mm Panel Height, 575 mm Panel Width, IP23, DIN Mounting, 1/1.2 mm Galvanized Steel, Black

Key Specifications

Brand	B&R
Product Type	Meter Boxes Domestic
SKU	B&RNSW/BP/GD10
Color	Black Show more colours

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Designed for both single and multi-phase installations Suitable for domestic and light commercial installations Provides versatility with a large range of products and accessories Entry level range of enclosures Top hinged with panel DIN panel cut-out Earth and neutral links NOT included Manufactured from 1.0mm or 1.2mm galvanised steel to Z275
Standard Pack Size	1
UNSPSC Class	39121100
UOM	EA
Vendor Product	NSW/BP/GD10
Colour	Black
IP Rating	IP23
Material	Steel
Number Of Poles	12 Pole
Finish	Galvanised
Mounting Method	DIN
Enclosure Depth	270mm
Enclosure Height	600mm
Enclosure Width	600mm
Door Type	Top Hinged
