Combo RCD/MCB RCBO 1P+ N 6A6kA 1Module 18mm DIN 35 Rail
Loading...
Description
Combination RCD Circuit Breakers, RCBO Type A, 1 Pole + N, 6 Amp, 240 Volt, 10 mA, 6 kA, 1 Module 18mm, DIN Rail Mounting, C Curve
Key Specifications
| Brand |
NHP
|
|---|---|
| Range Name |
MOD6
|
| Product Type |
RCD Circuit Breakers
|
| SKU |
NHPM6RCBD0610CAN
|
| Color |
Black
Show more colours
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | M6RCBD0610CAN |
| Interrupt Capacity | 6 kA |
| Number Of Poles | 1 Pole |
| Trip Sensitivity | 10 mA |
| IP Rating | IP40/20 |
| Connection Type | Pin |
| Trip Characteristic | C Curve |
| Height | 86mm |
| Width | 18mm |
| Depth | 76mm |
| Frequency | 50/60 Hz |
| Mounting Method | DIN Rail |
| Temperature | -5 to 55 deg C |
| Terminal Connection | 16 sq-mm/25 sq-mm Flex/25 sq-mm/16 sq-mm Rigid |
| Modules | 1 Module 18mm |
