Cabac Bootlace Ferrule Insulated 2.5mm 2.6x8mm Pin 14mm OAL Grey

Description

Bootlace Ferrule, Insulated, Conductor Size: 2.5 sq-mm, Number of Conductors: 1, 14mm Overall Length, Collar Inside Diameter: 4.9mm, Pin Diameter: 2.6mm, Pin Length: 8mm, Crimping Die: HNKE12, HNKE3, HNKE6, HNKE5, HNKE9, HNKE10 and HNKE11, Sleeve Material: Copper, Contact Material: Copper, Tin Plated Finish, Grey Insulation, 100 Pack

Key Specifications

Brand	Cabac
Range Name	Pre-Insulated Terminals
Product Type	Bootlace Ferrules
SKU	CAABLP250
Color	Black Show more colours

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Used to terminate conductors by containing the strands in a thin walled copper sleeve that is crimped onto the conductor Sleeve ensures no stray conductor strands or breaks from screw Crimp holds on sleeve until housing screw makes connection Crimp with one of our HNKE range of crimp tools Halogen free
Standard Pack Size	100
UNSPSC Class	39121400
UOM	EA
Vendor Product	BLP250
Pack Size	100 Pack
Finish	Tin Plated
Insulation Colour	Grey
Overall Length	14mm
Collar Inside Diameter	4.9mm
Contact Material	Copper
Crimping Die	HNKE12, HNKE3, HNKE6, HNKE5, HNKE9, HNKE10 and HNKE11
Number of Conductors	1
Pin Diameter	2.6mm
Pin Length	8mm
Sleeve Material	Copper
